Hikvision DS-3E0505P-E 4 Port Gigabit Unmanaged POE+ 65W Switch

DS-3E0505P-E
Shell: Metal material, fan-free design
Net Weight: 0.2 kg (0.4 lb)
Gross Weight: 0.84 kg (1.85 lb)
Dimensions (W × H × D): 105 mm × 27.6 mm × 83.1 mm (4.1'' × 1.1'' × 3.3'')
Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature: –40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity: 5% to 95% (no condensation)
Relative Humidity: 5% to 95% (no condensation)
Power Supply: 48 VDC, 1.35 A
Max. Power Consumption: 65 W
Power Consumption in Idle: 5 W
Installation Mode: Desk-Mounted,Wall-Mounted
Surge Protection: 6 KV
Ports: 4 × Gigabit PoE port,1 × Gigabit RJ45 port
MAC Address Table: 2 K
Switching Capacity: 10 Gbps
Packet Forwarding Rate: 7.44 Mpps
Internal Cache: 1 Mbits
PoE Standard: IEEE 802.3af;IEEE 802.3at
PoE Power Pin: End-span: 1/2(+), 3/6(-)
PoE Port: PoE: Ports 1 to 4
Max. Port Power: 30W
PoE Power Budget: 60W
EMC: FCC (47 CFR Part 15, Subpart B),CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)
Safety: UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
Chemistry: CE-RoHS (2011/65/EU)
Features: 4 ports
Type: PoE
Warranty
Warranty: 3 Years
